YT33PL 2-WAY CORNER
Colour: aluminum
Material: aluminum 6082
Number of points: 3-point
Edge dimension: 29cm
System: YT33PL
Type: Corner
Main Pipe Diameter: 51mm
Wall thickness main pipe: 2mm
Brace diameter: 16mm
Wall thickness Brace: 2mm
YT33PL circle truss system
| Standard available lengths and codes | ||||
|---|---|---|---|---|
| Diameter(Metres) | Diameter(Feet) | Deg | Weight(kg) | Code |
| 2.00 | 6.56 | 90° | 8.00 | YT33R10-90PL |
| 3.00 | 9.84 | 90° | 10.50 | YT33R15-90PL |
| 4.00 | 13.12 | 90° | 13.00 | YT33R20-90PL |
| 5.00 | 16.40 | 45° | 10.00 | YT33R25-45PL |
| 6.00 | 19.68 | 45° | 10.20 | YT33R30-45PL |
| 7.00 | 22.96 | 45° | 11.80 | YT33R35-45PL |
| 8.00 | 26.24 | 45° | 13.00 | YT33R40-45PL |
| 9.00 | 29.52 | 45° | 14.50 | YT33R45-45PL |
| 10.00 | 32.80 | 30° | 11.40 | YT33R50-30PL |
| other lengths available on request | ||||
parameter
- Colour: Black / Aluminum (Other colours available on request)
- Material: aluminum 6082
- Number of points: 3-point
- Edge dimension: 29cm
- System: YT33PL
- Type: circle
- Diameter circle: 2-10m
- Main Pipe Diameter: 51mm
- Wall thickness main pipe: 2mm
- Brace diameter: 16mm
- Wall thickness Brace: 2mm
